Toro 53707 Jar Top Valve with Flow Control, 1 in, Female Slip, Stainless Steel Body

Toro

Toro 53707 Jar Top Valve with Flow Control, 1 in, Female Slip, Stainless Steel Body

$31.99$31.99
Toro 53707 Jar Top Valve with Flow Control, 1 in, Female Slip, Stainless Steel Body
  • Body Material: Stainless Steel
  • Connection Type: Female Slip
  • Diaphragm Material: Stainless Steel
  • Nominal Size: 1 in
  • Overall Height: 6-1/2 in
  • Model #: 53707
  • UPC #: 021038537078
  • SKU: 3568300

Your shopping list will be used for pickup in-store

Product Details

Built to take the pressure, the Toro 1 in (2.5 cm) in-line jar-top valve operates in the widest flow and pressure ranges from 0.25 to 30 gpm (0.9 to 113.6 lpm) and 10 to 150 psi (0.7 to 10.3 bar). These valves are typically installed below ground and are housed in a valve box keeping them securely out of sight. The threaded bonnet jar top system enables fast and easy servicing.

Key Features

  • Adjustable flow control reduces water waste from misting and fogging
  • Spray-free internal as well as external bleed allow manual operation
  • Jar-top design for fast no-tools access
  • Rugged, double-beaded SANTOPRENE diaphragm provides leakproof seal
  • Spring and plunger enclosed in solenoid
  • Reduces wear and increases reliability
  • Reduces water waste from misting and fogging
  • Manually activate at valve box, internal bleed eliminates flooding at valve location

Item Specifications

Body MaterialStainless Steel
Connection TypeFemale Slip
Diaphragm MaterialStainless Steel
Nominal Size1 in
Overall Height6-1/2 in
Overall Length17.2 in
Overall Width8.8 in
Pressure Rating10 to 150 psi
